| Manufacturer | Wacker Neuson |
| Model | ST35 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2020-2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.0 HP | 55.2 kW |
| Lifting Capacity (35% Tipping) | 2450 lbs | 1111 kg |
| Lifting Capacity (50% Tipping) | 3500 lbs | 1588 kg |
| Operating Weight | 9827 lbs | 4457 kg |
| Tipping Load | 7000 lbs | 3175 kg |
| Lift Breakout Force | 6167 lbs | 2797 kg |
| Tilt Breakout Force | 6717 lbs | 3047 kg |
| Max. Travel Speed | 7.5 mph | 15.4 km |
| Ground Pressure | 4.4 psi | 30.3 kpa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 22.5 GPM | 85.2 LPM |
| Relief Pressure | 3338 psi | 230 Bar |
| Optional High Flow | 35.9 GPM | 135.9 LPM |
| Hydraulic Capacity | 3.4 gal | 12.9 L |
Engine Specs
| Manufacturer | Perkins |
| Model | 854F-E34TTF |
| Type | Diesel |
| Cylinders | 4 |
| Rated Speed | 2500 RPM |
| Torque Power | 1600 RPM |
| Combustion | Direct injection |
| Emissions | Tier 4F |
| Compression Ratio | 17.1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.0 HP | 55.2 kW |
| Net Power | 73.8 HP | 55.0 kW |
| Displacement | 207 in. | 3397 cc |
| Bore | 3.9 in. | 9.9 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | 215 ft-lb | 291 N∙m |
| Coolant Capacity | 1.5 gal | 6.0 L |
| Engine Oil Capacity | 2.2 gal | 8.5 L |
| Fuel Tank Capacity | 24.3 gal | 92.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 81.9 in. | 208.0 cm |
| Bucket Hinge Pin | 125.9 in. | 319.8 cm |
| Width | 76.0 in. | 193.0 cm |
| Length | 144.2 in. | 366.3 cm |
| Dump Height | 95.2 in. | 241.8 cm |
| Dump Reach | 30.5 in. | 77.5 cm |
| Ground Clearance | 9.4 in. | 23.9 cm |
| Dump Angle | 44° |
| Rollback Angle | |
| Departure Angle | 30° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 17.7 in. | 45.0 cm |
| Track Length | 116.1 in. | 294.9 cm |
| Ground Contact Length | 63.2 in. | 160.5 cm |
