| Manufacturer | ASV |
| Model | RS 60 |
| Type | Skid steer loader |
| Lift Design | Radial |
| Years Made | 2017-2022 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 60 HP | 44.7 kW |
| Lifting Capacity (35% Tipping) | ||
| Lifting Capacity (50% Tipping) | 2000 lbs | 907.2 kg |
| Operating Weight | 6370 lbs | 2889.4 kg |
| Tipping Load | 4000 lbs | 1814.4 kg |
| Lift Breakout Force | 4750 lbs | 2154.6 kg |
| Tilt Breakout Force | 4750 lbs | 2154.6 kg |
| Max. Travel Speed | 12.0 mph | 19.3 km |
| Ground Pressure |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 17.1 GPM | 65.0 LPM |
| Relief Pressure | 3335 psi | 230 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 8.0 gal | 30.3 L |
Engine Specs
| Manufacturer | Perkins |
| Model | 404D-22T |
| Type | Diesel |
| Cylinders | 4 |
| Rated Speed | 3000 RPM |
| Torque Power | 1800 RPM |
| Combustion | Indirect injection |
| Emissions | Stage IIIA/Tier 4 |
| Compression Ratio | 23.3:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 60.0 HP | 44.7 kW |
| Displacement | 135 cu in. | 2212 cc |
| Bore | 3.3 in. | 8.4 cm |
| Stroke | 3.9 in. | 10.0 cm |
| Peak Torque | 140 ft-lb | 189.8 N∙m |
| Coolant Capacity | 3.5 gal | 13.0 L |
| Engine Oil Capacity | 2.8 gal | 10.6 L |
| Fuel Tank Capacity | 25.0 gal | 94.6 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 87.0 in. | 202.3 cm |
| Bucket Hinge Pin | 118.0 in. | 332.7 cm |
| Width | 66.0 in. | 175.3 cm |
| Length | 136.6 in. | 388.1 cm |
| Dump Height | 87.0 in. | 221.0 cm |
| Dump Reach | 21.7 in | 10.0 in. |
| Ground Clearance | 10.0 in. | 25.4 cm |
| Dump Angle | 40° |
| Rollback Angle | 27° |
| Departure Angle | 28° |
