| Manufacturer | ASV |
| Model | RT 30 |
| Type | Compact track loader |
| Lift Design | Radial |
| Years Made | Unknown |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 32.7 HP | 24.4 kW |
| Lifting Capacity (35% Tipping) | 665 lbs | 301.6 kg |
| Lifting Capacity (50% Tipping) | 950 lbs | 430.9 kg |
| Operating Weight | 3600 lbs | 1632.9 kg |
| Tipping Load | 1900 lbs | 861.8 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 5.7 mph | 9.2 km |
| Ground Pressure | 3.0 psi | 20.7 kPa |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 11.3 GPM | 42.8 LPM |
| Relief Pressure | 3000 psi | 206.8 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 4.0 gal | 15.1 L |
Engine Specs
| Manufacturer | Perkins |
| Model | 403D-15 |
| Type | Diesel |
| Cylinders | 3 |
| Rated Speed | 2800 RPM |
| Torque Power | 1400 RPM |
| Combustion | Indirect injection |
| Emissions | Stage V/EPA Tier 4 |
| Compression Ratio | 22.2:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 24.7 HP | 18.4 kW |
| Displacement | 103.7 cu in. | 1699.3 cc |
| Bore | 3.3 in. | 8.4 cm |
| Stroke | 3.9 in. | 10.0 cm |
| Peak Torque | 66.4 ft-lb | 90.0 N∙m |
| Coolant Capacity | 1.6 gal | 6.0 L |
| Engine Oil Capacity | 1.6 gal | 6.0 L |
| Fuel Tank Capacity | 10.0 gal | 98.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 72.5 in. | 184.2 cm |
| Bucket Hinge Pin | 101.0 in. | 256.5 cm |
| Width | 48.0 in. | 121.9 cm |
| Length | 114.0 in. | 289.6 cm |
| Dump Height | 77.0 in. | 195.6 cm |
| Dump Reach | 18.0 in. | 45.7 cm |
| Ground Clearance | 10.0 in. | 25.4 cm |
| Dump Angle | 40° |
| Rollback Angle | 18° |
| Departure Angle | 55° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 11.0 in. | 27.9 cm |
| Track Length | 55.0 in. | 139.7 cm |
| Track Weight | ||
| Ground Contact Area | 1,183 in² | 7,632 cm² |
