| Manufacturer | ASV |
| Model | VT-100 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2023-2026 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 103.5 HP | 77.2 kW |
| Lifting Capacity (35% Tipping) | 3500 lbs | 1588 kg |
| Lifting Capacity (50% Tipping) | 5000 lbs | 2268 kg |
| Operating Weight | 10835 lbs | 4915 kg |
| Tipping Load | 10000 lbs | 4536 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 9.3 mph | 14.9 km |
| Ground Pressure | 4.0 psi | 27.6 kPa |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 23.0 GPM | 87.0 LPM |
| Relief Pressure | 3481 psi | 227.5 bar |
| Optional Flow | 41.0 GPM | 155.0 LPM |
| Hydraulic Capacity |
Engine Specs
| Manufacturer | Yanmar |
| Model | 4TNV94FHT |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4F/Stage V |
| Rated Speed | 2500 RPM |
| Torque Power | 1700 RPM |
| Combustion | Direct injection |
| Compression Ratio | 17.6 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 103.5 HP | 88.0 kW |
| Net Power | ||
| Displacement | 186.3 cu in. | 3054 cc |
| Bore | 3.7 in. | 9.4 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | 291 ft-lb | 395 N∙m |
| Coolant Capacity | ||
| Engine Oil Capacity | ||
| Fuel Tank Capacity | 34.0 gal | 128.7 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 83.5 in. | 212.1 cm |
| Bucket Hinge Pin | 132.0 in. | 335.3 cm |
| Width | 76.0 in. | 193.0 cm |
| Length | 154.0 in. | 391.2 cm |
| Dump Height | ||
| Dump Reach | 43.0 in. | 109.2 cm |
| Ground Clearance | 15.0 in. | 38.1 cm |
| Dump Angle | 42° |
| Rollback Angle | 29.5° |
| Departure Angle | 28° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 18.0 in. | 45.7 cm |
| Track Length | 123.0 in. | 312.4 cm |
| Ground Contact Length | 71.0 in. | 180.3 cm |
