| Manufacturer | Bobcat |
| Model | 5610 |
| Type | Toolcat |
| Years Made | 2008-2020 |
| Variants | 5610 F-Series 5610 D-Series |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 61.0 HP | 45.5 kW |
| Rated Operating Capacity | 1500 lbs | 680.4 kg |
| Machine Rated Capacity | 2200 lbs | 997.9 kg |
| Max. Cargo Capacity | – | – |
| Total Rated Capacity | 4200 lbs | 1905.1 kg |
| Operating Weight | 5835 lbs | 2646.7 kg |
| Tipping Load | 3000 lbs | 1360.8 kg |
| Max. Travel Speed | 17.0 mph | 27.3 km |
| Optional High Speed | 18.0 mph | 28.9 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 18.9 GPM | 71.4 LPM |
| Relief Pressure | 3000 psi | 206.8 Bar |
| Optional Flow | 27.9 GPM | 107.4 LPM |
| Hydraulic Capacity | 10.0 gal | 37.9 L |
Engine Specs
| Manufacturer | Bobcat |
| Model | D24NAP Turbo |
| Type | Diesel |
| Cylinders | 4 |
| Rated Speed | 2600 RPM |
| Torque Power | 1800 RPM |
| Combustion | Direct injection |
| Compression Ratio | 17.0:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 61.0 HP | 45.5 kW |
| Displacement | 146 cu.in. | 2392 cc |
| Bore | 3.5 in. | 9.0 cm |
| Stroke | 3.7 in. | 9.4 cm |
| Peak Torque | 166 ft-lb | 225 N∙m |
| Coolant Capacity | ||
| Engine Oil Capacity | ||
| Fuel Tank Capacity | 20.0 gal | 75.7 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 80.7 in. | 205.0 cm |
| Bucket Hinge Pin | 84.3 in. | 214.1 cm |
| Width | 60.5 in. | 153.7 cm |
| Length | 186.8 in. | 474.5 cm |
| Dump Height | 62.3 in. | 158.2 cm |
| Dump Reach | 42.8 in. | 108.7 cm |
| Ground Clearance | 10.2 in. | 25.9 cm |
| Dump Angle | 40° |
| Rollback Angle | 30° |
| Departure Angle | 28° |
Find Bobcat 5610 Parts on Amazon
Tire Size
| Front | 10.5 x 27 |
| Rear | 10.5 x 27 |
