| Manufacturer | Bobcat |
| Model | 722 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 1976-1979 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 30.0 HP | 22.4 kW |
| Lifting Capacity (35% Tipping) | 800 lbs | 362.9 kg |
| Lifting Capacity (50% Tipping) | 1200 lbs | 544.3 kg |
| Operating Weight | 4400 lbs | 1995.8 kg |
| Tipping Load | 2400 lbs | 1088.6 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 6.3 mph | 10.1 km |
Cycle Time
| Raise Lift Arms | 4.7 sec. |
| Lower Lift Arms | 2.8 sec. |
| Bucket Rollback | 1.4 sec. |
| Bucket Dump | 1.4 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 10.0 GPM | 37.9 LPM |
| Relief Pressure | 2100 psi | 144.8 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 17.0 gal | 64.4 L |
Engine Specs
| Manufacturer | Ford |
| Model | FL98 |
| Type | Gasoline |
| Cylinders | 4 |
| Rated Speed | 2500 RPM |
| Torque Power | 1800 RPM |
| Combustion | |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 30.0 HP | 22.4 kW |
| Net Power | 28.0 HP | 20.9 kW |
| Displacement | 98 cu in. | 1606 cc |
| Bore | 3.3 in. | 8.3 cm |
| Stroke | 3.3 in. | 8.3 cm |
| Peak Torque | 71 ft-lb | 96 N∙m |
| Coolant Capacity | ||
| Engine Oil Capacity | 1.0 gal | 3.8 L |
| Fuel Tank Capacity | 17.0 gal | 64.4 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 81.5 in. | 204.7 cm |
| Bucket Hinge Pin | 109.0 in. | 276.9 cm |
| Width | 45.5 in. | 115.6 cm |
| Length | 114.0 in. | 289.3 cm |
| Dump Height | 86.0 in. | 218.4 cm |
| Dump Reach | 20.0 in. | 50.4 cm |
| Ground Clearance | 8.1 in. | 20.6 cm |
| Dump Angle | 36° |
| Rollback Angle | 26° |
| Departure Angle | 26° |
