| Manufacturer | Bobcat |
| Model | T7X |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 100.0 HP | 74.5 kW |
| Lifting Capacity (35% Tipping) | 3056 lbs | 1386.2 kg |
| Lifting Capacity (50% Tipping) | 4355 lbs | 1975.4 kg |
| Operating Weight | 12590 lbs | 5710.7 kg |
| Tipping Load | 8743 lbs | 3965.8 kg |
| Lift Breakout Force | 8118 lbs | 3682.3 kg |
| Tilt Breakout Force | 8218 lbs | 3727.6 kg |
| Max. Travel Speed | 5.7 mph | 9.1 km |
| Optional High Speed | 8.7 mph | 14.0 km |
| Ground Pressure | 5.2 psi | 35.9 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | N/A | – |
| Relief Pressure | N/A | – |
| Optional Flow | N/A | – |
| Hydraulic Capacity | N/A | – |
Engine Specs
| Manufacturer | Bobcat |
| Type | Permanent Magnet Brushless |
| Emissions | Zero Emission |
| Rated Speed | 2800 RPM |
| Battery Type | Lithium Ion |
| Working Duration | 4/6 Hours |
| Voltage | 336-465 VDC |
| Charging Time | ~12 hours (240V, 40A) |
| US | Metric | |
|---|---|---|
| Gross Power | 100.0 HP | 74.5 kW |
| Gross Battery Capacity | 97.4 hph | 72.6 kW |
| Motor Brake Cavity | 0.25 gal | 1.0 L |
| Coolant Capacity | 2.0 gal | 7.6 L |
| Battery Coolant Capacity | 2.75 gal | 10.4 L |
| Air Condition Fluid Capacity | 2.0 lbs | 0.9 kgs |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 80.9 in | 205.5 cm |
| Bucket Hinge Pin | 128.4 in. | 326.1 cm |
| Width | 76.2 in. | 193.5 cm |
| Length | 147.1 in. | 373.7 cm |
| Dump Height | ||
| Dump Reach | ||
| Ground Clearance | 8.8 in. | 22.4 cm |
| Dump Angle | 37° |
| Rollback Angle | 31° |
| Departure Angle | 27° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 12.6 in. | 32.0 cm |
| Track Length | 113.9 in. | 289.4 cm |
| Ground Contact Length | 59.3 in. | 150.5 cm |
