| Manufacturer | Case |
| Model | SR250 |
| Type | Compact track loader |
| Lift Design | Radial |
| Years Made | 2011-2020 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 90.0 HP | 67.1 kW |
| Lifting Capacity (35% Tipping) | 1800 lbs | 816.5 kg |
| Lifting Capacity (50% Tipping) | 2500 lbs | 1134.0 kg |
| Operating Weight | 7700 lbs | 3492.6 kg |
| Tipping Load | 5000 lbs | 2263.0 kg |
| Lift Breakout Force | 5680 lbs | 2576.4 kg |
| Tilt Breakout Force | 7480 lbs | 3392.9 kg |
| Max. Travel Speed | 7.0 mph | 11.3 km |
| Optional High Speed | 10.5 mph | 16.9 km |
Cycle Time
| Raise Lift Arms | 3.7 sec. |
| Lower Lift Arms | 1.9 sec. |
| Bucket Rollback | 2.0 sec. |
| Bucket Dump | 2.7 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 22.5 GPM | 91.5 LPM |
| Relief Pressure | 3000 psi | 207 Bar |
| Optional Flow | 34.6 GPM | 131.3 LPM |
| Hydraulic Capacity | 11.8 gal | 44.5 L |
Engine Specs
| Manufacturer | FPT |
| Model | F5C E5454 C* A003 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 3 |
| Rated Speed | 2500 RPM |
| Torque Power | 1400 RPM |
| Combustion | Direct Injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 90.0 HP | 67.1 kW |
| Net Power | 84.0 HP | 62.6 kW |
| Displacement | 195 cu in. | 3195 cc |
| Bore | 3.9 in. | 9.9 cm |
| Stroke | 4.1 in. | 10.4 cm |
| Peak Torque | 251 ft-lb | 340 N∙m |
| Coolant Capacity | 3.0 gal | 11.4 L |
| Engine Oil Capacity | 2.5 gal | 9.5 L |
| Fuel Tank Capacity | 25.5 gal | 96.5 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 78.8 in. | 200.2 cm |
| Bucket Hinge Pin | 123.3 in. | 313.2 cm |
| Width | 69.6 in. | 176.8 cm |
| Length | 142.2 in. | 361.2 cm |
| Dump Height | 100.9 in. | 256.3 cm |
| Dump Reach | 95.2 in. | 241.8 cm |
| Ground Clearance | 8.0 in. | 20.3 cm |
| Dump Angle | 38.1° |
| Rollback Angle | 30.7° |
| Departure Angle | 23.5° |
