| Manufacturer | Case |
| Model | TL100 wide track |
| Type | Mini track loader |
| Lift Design | Radial |
| Years Made | 2023-2026 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 24.8 HP | 18.5 kW |
| Lifting Capacity (35% Tipping) | 1102 lbs | 500 kg |
| Lifting Capacity (50% Tipping) | 1574 lbs | 714 kg |
| Operating Weight | 3783 lbs | 1716 kg |
| Tipping Load | 3148 lbs | 1428 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 4.7 mph | 7.5 km |
| Ground Pressure | 4.6 psi | 31.7 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 13.2 GPM | 50.0 LPM |
| Relief Pressure | 2800 psi | 193.1 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 4.5 gal | 17.0 L |
Engine Specs
| Manufacturer | Kubota |
| Model | D1305-E4B |
| Type | Diesel |
| Cylinders | 3 |
| Emissions | Tier 4 |
| Rated Speed | 2600 RPM |
| Torque Power | 1700 RPM |
| Combustion | Indirect injection |
| Compression Ratio | |
| Firing Order | 1-2-3 |
| US | Metric | |
|---|---|---|
| Gross Power | 24.8 HP | 18.5 kW |
| Net Power | 24.0 HP | 18.0 kW |
| Displacement | 77 cu in. | 1262 cc |
| Bore | 3.07 in. | 7.8 cm |
| Stroke | 3.46 in. | 8.0 cm |
| Peak Torque | 59.1 ft-lb | 80.1 N·m |
| Coolant Capacity | 0.9 gal | 3.5 L |
| Engine Oil Capacity | 1.5 gal | 5.7 L |
| Fuel Tank Capacity | 7.9 gal | 30.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 56.5 in. | 143.5 cm |
| Bucket Hinge Pin | 86.7 in. | 220.1 cm |
| Width | 40.4 in. | 102.6 cm |
| Length | 110.1 in. | 279.6 cm |
| Dump Height | 61.0 in. | 154.9 cm |
| Dump Reach | 20.1 in. | 51.1 cm |
| Ground Clearance | 8.7 in. | 22.2 cm |
| Dump Angle | 48° |
| Rollback Angle | 24° |
| Departure Angle | 24° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 10.0 in. | 25.0 cm |
| Track Length | 85.0 in. | 215.5 cm |
| Ground Contact Length | 41.9 in. | 106.5 cm |
