Cat 236B2 Specs

Cat 236B2 skid steer
ManufacturerCaterpillar
Model236B Series 2
TypeSkid steer loader
Lift DesignRadial
Years Made2007-Unknown

Operating Specifications

USMetric
Horsepower73.0 HP54.4 kW
Lifting Capacity (35% Tipping)1250 lbs567.0 kg
Lifting Capacity (50% Tipping)1950 lbs884.5 kg
Operating Weight7007 lbs3178.2 kg
Tipping Load4000 lbs1814.4 kg
Lift Breakout Force4650 lbs2109.2 kg
Tilt Breakout Force5484 lbs2487.5 kg
Max. Travel Speed7.5 mph12.1 km
Optional High Speed11.6 mph18.6 km

Cycle Time

Raise Lift Arms
Lower Lift Arms
Bucket Rollback
Bucket Dump

Hydraulic System

USMetric
Pump Flow22.0 GPM83.3 LPM
Relief Pressure3335 psi229.9 Bar
High FlowN/A
Hydraulic Capacity13.7 gal52.0 L

Engine Specs

ManufacturerCat
Model3044C DIT
TypeDiesel
Cylinders4
EmissionsTier 2 Compliant
Rated Speed2600 RPM
Torque Power1600 RPM
CombustionDirect injection
Compression Ratio16:2.1
Firing Order1-3-4-2
USMetric
Gross Power73.0 HP54.4 kW
Net Power71.0 HP52.9 kW
Displacement201 cu in.3394 cc
Bore3.7 in.9.4 cm
Stroke4.7 in.12.0 cm
Peak Torque
Coolant Capacity2.6 gal10.0 L
Engine Oil Capacity2.6 gal10.0 L
Fuel Tank Capacity23.8 gal90.0 L

Dimensions

USMetric
Height82.0 in.209.2 cm
Bucket Hinge Pin122.0 in.309.9 cm
Width66.0 in.167.6 cm
Length138.0 in.351.5 cm
Dump Height94.0 in.239.8 cm
Dump Reach21.0 in.54.1 cm
Ground Clearance9.3 in.23.5 cm
Dump Angle40°
Rollback Angle
Departure Angle28°

Tire Size

Front12×16.5
Rear12×16.5
