| Manufacturer | Caterpillar |
| Model | 250 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.0 HP | 55.0 kW |
| Lifting Capacity (35% Tipping) | 1882 lbs | 854 kg |
| Lifting Capacity (50% Tipping) | 2689 lbs | 1220 kg |
| Operating Weight | 7829 lbs | 3551 kg |
| Tipping Load | 5378 lbs | 2440 kg |
| Lift Breakout Force | 5948 lbs | 2698 kg |
| Tilt Breakout Force | 6784 lbs | 3077 kg |
| Max. Travel Speed | 8.0 mph | 12.9 km |
| Optional High Speed | 10.5 mph | 16.9 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 20.0 GPM | 75.7 LPM |
| Relief Pressure | 3335 psi | 230 Bar |
| High Flow | 30.0 GPM | 113.2 LPM |
| Hydraulic Capacity | 9.7 gal | 36.8 L |
Engine Specs
| Manufacturer | Cat |
| Model | C2.8T |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4F |
| Rated Speed | 2500 RPM |
| Torque Power | 1600 RPM |
| Combustion | Direct injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.0 HP | 55.0 kW |
| Net Power | 73.5 HP | 54.8 kW |
| Displacement | 171 cu in. | 2802 cc |
| Bore | 3.5 in. | 9.0 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | 221 ft-lb | 300 N∙m |
| Coolant Capacity | 3.0 gal | 11.4 L |
| Engine Oil Capacity | 2.2 gal | 8.2 L |
| Fuel Tank Capacity | 25.1 gal | 93.9 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 81.9 in. | 208.0 cm |
| Bucket Hinge Pin | 124.0 in. | 315.0 cm |
| Width | 66.0 in. | 167.7 cm |
| Length | 135.0 in. | 343.0 cm |
| Dump Height | 96.2 in. | 244.3 cm |
| Dump Reach | 17.6 in. | 44.8 cm |
| Ground Clearance | 7.7 in. | 19.5 cm |
| Dump Angle | 46° |
| Rollback Angle | 28° |
| Departure Angle | 23° |
