| Manufacturer | Caterpillar |
| Model | 262D3 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2019-2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.3 HP | 55.4 kW |
| Lifting Capacity (35% Tipping) | 2050 lbs | 929.9 kg |
| Lifting Capacity (50% Tipping) | 2700 lbs | 1224.7 kg |
| Operating Weight | 8296 lbs | 3763.0 kg |
| Tipping Load | 5400 lbs | 2449.4 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | 7335 lbs | 3327.1 kg |
| Max. Travel Speed | 7.7 mph | 15.5 km |
| Optional High Speed | 11 mph | 17.7 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 23.0 GPM | 87.1 LPM |
| Relief Pressure | 3335 psi | 230.0 Bar |
| High Flow | 32.0 GPM | 121.1 LPM |
| Hydraulic Capacity | 52.0 gal | 196.8 L |
Engine Specs
| Manufacturer | Cat |
| Model | C3.3B DIT |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 Final and EU Stage V |
| Rated Speed | 2400 RPM |
| Torque Power | 1500 RPM |
| Combustion | Direct injection |
| Compression Ratio | 17:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.3 HP | 55.4 kW |
| Net Power | 73.2 HP | 54.6 kW |
| Displacement | 203 cu in. | 3327 cc |
| Bore | 3.7 in. | 9.4 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | 265 ft-lb | 359.3 N∙m |
| Coolant Capacity | 3.7 gal | 14.0 L |
| Engine Oil Capacity | 3.0 gal | 11.4 L |
| Fuel Tank Capacity | 27.7 gal | 104.9 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 83.1 in. | 211.1 cm |
| Bucket Hinge Pin | 124.9 in. | 317.2 cm |
| Width | 66.0 in. | 167.6 cm |
| Length | 146.2 in. | 371.3 cm |
| Dump Height | 93.7 in. | 238.0 cm |
| Dump Reach | 30.9 in. | 78.6 cm |
| Ground Clearance | 8.9 in. | 22.6 cm |
| Dump Angle | 51° |
| Rollback Angle | |
| Departure Angle | 26° |
