| Manufacturer | Caterpillar |
| Model | 272C |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2007-2012 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 94.0 HP | 70.1 kW |
| Lifting Capacity (35% Tipping) | 2600 lbs | 1179.3 kg |
| Lifting Capacity (50% Tipping) | 3250 lbs | 1474.2 kg |
| Operating Weight | 8292 lbs | 3761.2 kg |
| Tipping Load | 6500 lbs | 2948.4 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | 7315 lbs | 3318.0 kg |
| Max. Travel Speed | 7.2 mph | 11.6 km |
| Optional High Speed | 10.0 mph | 16.1 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 22.0 GPM | 83.3 LPM |
| Relief Pressure | 3335 psi | 229.9 Bar |
| High Flow | 33.0 GPM | 124.9 L |
| Hydraulic Capacity | 15.0 gal | 56.8 L |
Engine Specs
| Manufacturer | Cat |
| Model | 3044C DIT |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 3 |
| Rated Speed | 2600 RPM |
| Torque Power | 1600 RPM |
| Combustion | Direct injection |
| Compression Ratio | 16:2.1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 94.0 HP | 74.1 kW |
| Net Power | 90.0 HP | 67.1 kW |
| Displacement | 201 cu in. | 3394 cc |
| Bore | 3.7 in. | 9.4 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | ||
| Coolant Capacity | 3.7 gal | 14.0 L |
| Engine Oil Capacity | 2.6 gal | 10.0 L |
| Fuel Tank Capacity | 26.0 gal | 98.4 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 82.0 in. | 209.2 cm |
| Bucket Hinge Pin | 129.0 in. | 327.7 cm |
| Width | 66.0 in. | 167.6 cm |
| Length | 150.0 in. | 381.0 cm |
| Dump Height | 97.9 in. | 248.7 cm |
| Dump Reach | 30.0 in. | 76.2 cm |
| Ground Clearance | 8.8 in. | 22.5 cm |
| Dump Angle | 51° |
| Rollback Angle | |
| Departure Angle | 26° |
