| Manufacturer | Caterpillar |
| Model | 285 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 111.0 HP | 82.8 kW |
| Lifting Capacity (35% Tipping) | 4461 lbs | 2023 kg |
| Lifting Capacity (50% Tipping) | 6372 lbs | 2891 kg |
| Operating Weight | 13497 lbs | 6122 kg |
| Tipping Load | 12745 lbs | 5781 kg |
| Lift Breakout Force | 8730 lbs | 3960 kg |
| Tilt Breakout Force | 13920 lbs | 6314 kg |
| Max. Travel Speed | 7.7 mph | 12.4 km |
| Ground Pressure | 5.6 psi | 38.4 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 23.0 GPM | 86.4 LPM |
| Relief Pressure | 3500 psi | 241.3 Bar |
| High Flow | 34.0 GPM | 128.3 LPM |
| Hydraulic Capacity | 10.8 gal | 41.0 L |
Engine Specs
| Manufacturer | Cat |
| Model | C3.6TA |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4F |
| Rated Speed | 2400 RPM |
| Torque Power | 1500 RPM |
| Combustion | Direct injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 111.0 HP | 82.8 kW |
| Net Power | 109.0 HP | 81.3 kW |
| Displacement | 221 cu in. | 3622 cc |
| Bore | 3.9 in. | 9.8 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | 370 ft-lb | 501 N∙m |
| Coolant Capacity | 4.6 gal | 17.5 L |
| Engine Oil Capacity | 2.4 gal | 9.0 L |
| Fuel Tank Capacity | 36.0 gal | 136.1 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 87.8 in. | 223.0 cm |
| Bucket Hinge Pin | 146.6 in. | 372.4 cm |
| Width | 79.8 in. | 202.8 cm |
| Length | 157.4 in. | 399.8 cm |
| Dump Height | 119.6 in. | 303.9 cm |
| Dump Reach | 34.7 in. | 88.2 cm |
| Ground Clearance | 11.0 in. | 28.0 cm |
| Dump Angle | 40.5° |
| Rollback Angle | 27.2° |
| Departure Angle | 26° |
Tire Size
| US | Metric | |
|---|---|---|
| Track Width | 15.7 in. | 39.9 cm |
| Track Length | 132.3 in. | 336.0 cm |
| Ground Contact Length | 72.0 in. | 183.0 cm |
