Manufacturer | John Deere |
Model | 332D |
Type | Compact track loader |
Lift Design | Vertical |
Years Made | 2009-2013 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 68.0 HP | 50.7 kW |
Lifting Capacity (35% Tipping) | 2650 lbs | 1202 kg |
Lifting Capacity (50% Tipping) | 3200 lbs | 1452 kg |
Operating Weight | 9170 lbs | 4162 kg |
Tipping Load | 6400 lbs | 2906 kg |
Lift Breakout Force | 3350 lbs | 1521 kg |
Tilt Breakout Force | 6600 lbs | 2996 kg |
Max. Travel Speed | 7.0 mph | 11.3 km |
Optional High Speed | 12.0 mph | 19.3 km |
Cycle Time
Raise Lift Arms | |
Lower Lift Arms | |
Bucket Rollback | |
Bucket Dump |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 25.0 GPM | 94.6 LPM |
Relief Pressure | 3450 psi | 237.9 Bar |
Optional Flow | 38.0 GPM | 143.8 LPM |
Hydraulic Capacity |
Engine Specs
Manufacturer | John Deere |
Model | PowerTech E 5030HT |
Type | Diesel |
Cylinders | 5 |
Emissions | Tier 3/Stage IIIA |
Rated Speed | 2400 RPM |
Torque Power | 1950 RPM |
Combustion | Direct injection |
Compression Ratio | 18.2:1 |
Firing Order | 1-2-4-5-3 |
US | Metric | |
---|---|---|
Gross Power | 95.0 HP | 66.7 kW |
Net Power | 89.0 HP | 71.1 kW |
Displacement | 186 cu in. | 3319 cc |
Bore | 3.4 in. | 8.6 cm |
Stroke | 4.1 in. | 10.5 cm |
Peak Torque | 252 ft-lb | 341 N∙m |
Coolant Capacity | ||
Engine Oil Capacity | 2.7 gal | 10.0 L |
Fuel Tank Capacity | 29.0 gal | 111 L |
Dimensions
US | Metric | |
---|---|---|
Height | 84.6 in. | 215 cm |
Bucket Hinge Pin | 127.1 in. | 323 cm |
Width | 78.0 in. | 199 cm |
Length | 142.0 in. | 360 cm |
Dump Height | 102.0 in. | 259 cm |
Dump Reach | 31.6 in. | 79.8 cm |
Ground Clearance | 10.8 in. | 27.5 cm |
Dump Angle | 45° |
Rollback Angle | 35° |
Departure Angle | 31° |
