| Manufacturer | Kubota |
| Model | SVL75-2 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2014-2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.3 HP | 55.4 kW |
| Lifting Capacity (35% Tipping) | 2300 lbs | 1043.3 kg |
| Lifting Capacity (50% Tipping) | 3285 lbs | 1490.1 kg |
| Operating Weight | 9300 lbs | 4218.4 kg |
| Tipping Load | 6570 lbs | 2980.1 kg |
| Lift Breakout Force | 4770 lbs | 2163.6 kg |
| Tilt Breakout Force | 6200 lbs | 2812.3 kg |
| Max. Travel Speed | 7.1 mph | 11.5 km |
| Ground Pressure | 5.8 psi | 40.0 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 17.4 GPM | 66.0 LPM |
| Relief Pressure | 3250 psi | 224.0 Bar |
| Optional Flow | 29.3 GPM | 110.9 LPM |
| Hydraulic Capacity | 9.2 gal | 35.0 L |
Engine Specs
| Manufacturer | Kubota |
| Model | V3307-CR-TE4 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 |
| Rated Speed | 2400 RPM |
| Torque Power | |
| Combustion | Direct injection |
| Compression Ratio | 15:6 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.3 HP | 55.4 kW |
| Net Power | 68.8 HP | 51.3 kW |
| Displacement | 203.3 cu in. | 3331 cc |
| Bore | 3.7 in. | 9.4 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | ||
| Coolant Capacity | ||
| Engine Oil Capacity | ||
| Fuel Tank Capacity | 24.6 gal | 93.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 82.0 in. | 208.3 cm |
| Bucket Hinge Pin | 119.1 in. | 302.5 cm |
| Width | 65.9 in. | 167.5 cm |
| Length | 140.8 in. | 357.6 cm |
| Dump Height | ||
| Dump Reach | 41.7 in. | 106.0 cm |
| Ground Clearance | 11.7 in. | 29.6 cm |
| Dump Angle | 40° |
| Rollback Angle | 27° |
| Departure Angle | 32° |
Tire Size
| US | Metric | |
|---|---|---|
| Track Width | 12.6 in. | 32.0 cm |
| Track Length | 109 in. | 276.8 cm |
| Ground Contact Length | 56.5 in. | 143.6 cm |
