| Manufacturer | Kubota |
| Model | SVL75-3 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2023-2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.3 HP | 55.4 kW |
| Lifting Capacity (35% Tipping) | 2490 lbs | 1129 kg |
| Lifting Capacity (50% Tipping) | 3557 lbs | 1613 kg |
| Operating Weight | 9190 lbs | 4169 kg |
| Tipping Load | 7112 lbs | 3226 kg |
| Lift Breakout Force | 4723 lbs | 2142 kg |
| Tilt Breakout Force | 6191 lbs | 2808 kg |
| Max. Travel Speed | 8.6 mph | 13.7 km |
| Ground Pressure | 4.8 psi | 33.1 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 19.2 GPM | 72.7 LPM |
| Relief Pressure | 3185 psi | 219.6 Bar |
| Optional Flow | 29.8 GPM | 112.8 LPM |
| Hydraulic Capacity | 12.2 gal | 46.0 L |
Engine Specs
| Manufacturer | Kubota |
| Model | V3307-TE5A |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier4 + EU Stage V |
| Rated Speed | 2400 RPM |
| Torque Power | 1400 RPM |
| Combustion | Direct injection |
| Compression Ratio | 15:6 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.3 HP | 55.4 kW |
| Net Power | 73.2 HP | 54.6 kW |
| Displacement | 203.3 cu in. | 3331 cc |
| Bore | 3.7 in. | 9.4 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | ||
| Coolant Capacity | ||
| Engine Oil Capacity | ||
| Fuel Tank Capacity | 25.0 gal | 94.6 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 81.8 in. | 207.8 cm |
| Bucket Hinge Pin | 122.7 in. | 311.7 cm |
| Width | 69.1 in. | 167.5 cm |
| Length | 140.8 in. | 175.5 cm |
| Dump Height | ||
| Dump Reach | 39.6 in. | 100.7 cm |
| Ground Clearance | 11.7 in. | 29.6 cm |
| Dump Angle | 38.5° |
| Rollback Angle | 27° |
| Departure Angle | 31.1° |
Tire Size
| US | Metric | |
|---|---|---|
| Track Width | 15.8 in. | 40.0 cm |
| Track Length | 112 in. | 284.4 cm |
| Ground Contact Length | 56.5 in. | 143.6 cm |
