| Manufacturer | Kubota |
| Model | Svl97-2 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2021-2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 96.4 HP | 71.9 kW |
| Lifting Capacity (35% Tipping) | 3200 lbs | 1451.5 kg |
| Lifting Capacity (50% Tipping) | 4570 lbs | 2072.9 kg |
| Operating Weight | 11570 lbs | 5248.1 kg |
| Tipping Load | 9150 lbs | 4150.4 kg |
| Lift Breakout Force | 6740 lbs | 3057.2 kg |
| Tilt Breakout Force | 7960 lbs | 3610.6 kg |
| Max. Travel Speed | 7.3 mph | 11.7 km |
| Ground Pressure | 4.5 psi | 31.0 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 23.1 GPM | 87.4 LPM |
| Relief Pressure | 3623 psi | 249.8 Bar |
| Optional Flow | 40.0 GPM | 151.4 LPM |
| Hydraulic Capacity | 18.0 gal | 68.0 L |
Engine Specs
| Manufacturer | Kubota |
| Model | V3800-TIEF4 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 |
| Rated Speed | 2400 RPM |
| Torque Power | |
| Combustion | Direct injection |
| Compression Ratio | 19.0 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 96.4 HP | 71.9 kW |
| Net Power | 87.0 HP | 64.9 kW |
| Displacement | 230 cu in. | 3769 cc |
| Bore | 3.9 in. | 10.0 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | ||
| Coolant Capacity | ||
| Engine Oil Capacity | ||
| Fuel Tank Capacity | 28.8 gal | 109.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 83.3 in. | 211.6 cm |
| Bucket Hinge Pin | 128.5 in. | 326.4 cm |
| Width | 77.2 in. | 196.2 cm |
| Length | 154.7 in. | 392.9 cm |
| Dump Height | ||
| Dump Reach | 40.7 in. | 103.5 cm |
| Ground Clearance | 11.5 in. | 29.3 cm |
| Dump Angle | 43° |
| Rollback Angle | 27° |
| Departure Angle | 31° |
Tire Size
| US | Metric | |
|---|---|---|
| Track Width | 17.7 in. | 45.0 cm |
| Track Length | 123.5 in. | 313.7 cm |
| Ground Contact Length | 65.6 in. | 166.7 cm |
