| Manufacturer | Kubota |
| Model | Svl97-3 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2025-2026 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 96.4 HP | 71.9 kW |
| Lifting Capacity (35% Tipping) | 3459 lbs | 1569 kg |
| Lifting Capacity (50% Tipping) | 4942 lbs | 2242 kg |
| Operating Weight | 11929 lbs | 5411 kg |
| Tipping Load | 9884 lbs | 4483 kg |
| Lift Breakout Force | 5277 lbs | 2394 kg |
| Tilt Breakout Force | 7646 lbs | 3468 kg |
| Max. Travel Speed | 8.4 mph | 13.5 km |
| Ground Pressure | 4.8 psi | 33.1 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 23.8 GPM | 90.1 LPM |
| Relief Pressure | 3553 psi | 245.0 Bar |
| Optional Flow | 41.2 GPM | 156.0 LPM |
| Hydraulic Capacity | 10.6 gal | 40.2 L |
Engine Specs
| Manufacturer | Kubota |
| Model | V3800-TIE5-L |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4F |
| Rated Speed | 2500 RPM |
| Torque Power | |
| Combustion | Direct injection |
| Compression Ratio | 19.0 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 96.4 HP | 71.9 kW |
| Net Power | 94.9 HP | 70.8 kW |
| Displacement | 230 cu in. | 3769 cc |
| Bore | 3.9 in. | 10.0 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | ||
| Coolant Capacity | ||
| Def Tank | 3.4 gal | 12.7 L |
| Fuel Tank Capacity | 30.6 gal | 115.7 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 83.1 in. | 211.2 cm |
| Bucket Hinge Pin | 128.5 in. | 326.4 cm |
| Width | 77.2 in. | 196.2 cm |
| Length | 153.6 in. | 390.1 cm |
| Dump Height | ||
| Dump Reach | 40.7 in. | 103.5 cm |
| Ground Clearance | 10.9 in. | 27.8 cm |
| Dump Angle | 43° |
| Rollback Angle | 28° |
| Departure Angle | 30.6° |
Tire Size
| US | Metric | |
|---|---|---|
| Track Width | 17.7 in. | 45.0 cm |
| Track Length | 123.7 in. | 314.1 cm |
| Ground Contact Length | 65.6 in. | 166.7 cm |
