| Manufacturer | Gehl |
| Model | 1350RT |
| Type | Compact track loader |
| Lift Design | Radial |
| Years Made | 2020-2026 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 46.6 HP | 34.3 kW |
| Lifting Capacity (35% Tipping) | 1349 lbs | 612 kg |
| Lifting Capacity (50% Tipping) | 1929 lbs | 875 kg |
| Operating Weight | 6510 lbs | 2953 kg |
| Tipping Load | 3858 lbs | 1750 kg |
| Lift Breakout Force | 3730 lbs | 1692 kg |
| Tilt Breakout Force | 3501 lbs | 1588 kg |
| Max. Travel Speed | 6.2 mph | 10.0 km |
| Ground Pressure | 6.0 psi | 41.4 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 16.8 GPM | 63.6 LPM |
| Relief Pressure | ||
| High Flow – XPS | N/A | |
| Hydraulic Capacity | 7.65 gal | 34.8 L |
Engine Specs
| Manufacturer | Yanmar |
| Model | 4TNV88C-KMS |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4F |
| Rated Speed | 2500 RPM |
| Torque Power | 1820 RPM |
| Combustion | Direct injection |
| Compression Ratio | 19.1 (Effective 17.2) |
| Firing Order | 1-3-4-2-1 |
| US | Metric | |
|---|---|---|
| Gross Power | 46.0 HP | 34.3 kW |
| Net Power | 44.5 HP | 33.0 kW |
| Displacement | 133.6 cu in. | 2189 cc |
| Bore | 3.46 in. | 8.8 cm |
| Stroke | 3.54 in. | 9.0 cm |
| Peak Torque | 108 ft-lb | 146 N∙m |
| Coolant Capacity | 2.0 gal | 7.9 L |
| Engine Oil Capacity | 1.4 gal | 6.4 L |
| Fuel Tank Capacity | 13.1 gal | 59.4 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 76.0 in. | 193.0 cm |
| Bucket Hinge Pin | 110.0 in. | 279.4 cm |
| Width | 57.0 in. | 144.8 cm |
| Length | 121.1 in. | 307.6 cm |
| Dump Height | 83.6 in. | 212.3 cm |
| Dump Reach | 23.3 in. | 59.2 cm |
| Ground Clearance | 8.4 in. | 21.3 cm |
| Dump Angle | 40° |
| Rollback Angle | 28° |
| Departure Angle | 28° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 11.8 in. | 30.0 cm |
| Track Length | 92.9 in. | 236.0 cm |
| Ground Contact Length | 45.2 in. | 114.8 cm |
