| Manufacturer | Gehl |
| Model | 1650RT |
| Type | Compact track loader |
| Lift Design | Radial |
| Years Made | 2019-2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 69.3 HP | 51.7 kW |
| Lifting Capacity (35% Tipping) | 1649 lbs | 748 kg |
| Lifting Capacity (50% Tipping) | 2357 lbs | 1069 kg |
| Operating Weight | 8020 lbs | 3638 kg |
| Tipping Load | 4716 lbs | 2139 kg |
| Lift Breakout Force | 5060 lbs | 2295 kg |
| Tilt Breakout Force | 4231 lbs | 1919 kg |
| Max. Travel Speed | 10.0 mph | 16.1 km |
| Ground Pressure | 7.0 psi | 48.3 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 18.8 GPM | 71.0 LPM |
| Relief Pressure | ||
| High Flow | N/A | |
| Hydraulic Capacity | 10.0 gal | 37.9 L |
Engine Specs
| Manufacturer | Yanmar |
| Model | 4TNV98C-NMS2 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 |
| Rated Speed | 2500 RPM |
| Torque Power | 1625 RPM |
| Combustion | Direct injection |
| Compression Ratio | 18.3 (Effective 16.4) |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 69.3 HP | 51.7 kW |
| Net Power | 68.4 HP | 51.0 kW |
| Displacement | 202.5 cu in. | 3318 cc |
| Bore | 3.9 in. | 9.8 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | 178 ft-lb | 241 N∙m |
| Coolant Capacity | 2.0 gal | 7.9 L |
| Engine Oil Capacity | 3.0 gal | 11.4 L |
| Fuel Tank Capacity | 17.0 gal | 64.4 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 78.0 in. | 198.1 cm |
| Bucket Hinge Pin | 120.0 in. | 304.8 cm |
| Width | 66.0 in. | 167.6 cm |
| Length | 126.0 in. | 320.0 cm |
| Dump Height | 92.0 in. | 233.7 cm |
| Dump Reach | 25.0 in. | 63.5 cm |
| Ground Clearance | 11.0 in. | 27.9 cm |
| Dump Angle | 39° |
| Rollback Angle | 28° |
| Departure Angle | 28° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 13.0 in. | 33.0 cm |
| Track Length | 94.0 in. | 238.0 cm |
| Ground Contact Length | 53.0 in. | 134.6 cm |
