| Manufacturer | Manitou |
| Model | 3200VT |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2022-2026 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 114.0 HP | 85.0 kW |
| Lifting Capacity (35% Tipping) | 3201 lbs | 1452 kg |
| Lifting Capacity (50% Tipping) | 4572 lbs | 2073 kg |
| Operating Weight | 11612 lbs | 5267 kg |
| Tipping Load | 9145 lbs | 4148 kg |
| Lift Breakout Force | 7491 lbs | 3398 kg |
| Tilt Breakout Force | 9903 lbs | 4492 kg |
| Max. Travel Speed | 8.0 mph | 12.9 km |
| Ground Pressure | 5.0 psi | 34.5 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 27.0 GPM | 102.2 LPM |
| Relief Pressure | ||
| Optional High Flow | 38.0 GPM | 143.8 LPM |
| Hydraulic Capacity | 17.0 gal | 64.4 L |
Engine Specs
| Manufacturer | Deutz |
| Model | TD 3.6 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 |
| Rated Speed | 2300 RPM |
| Torque Power | 1600 RPM |
| Combustion | Direct injection |
| Compression Ratio | 18:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 114.0 HP | 85.0 kW |
| Net Power | 108.0 HP | 80.8 kW |
| Displacement | 221 cu in. | 3622 cc |
| Bore | 3.9 in. | 9.8 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | 317 ft-lb | 430 N∙m |
| Coolant Capacity | 5.0 gal | 18.9 L |
| Engine Oil Capacity | 2.2 gal | 8.3 L |
| Fuel Tank Capacity | 32.0 gal | 121.1 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 82.9 in. | 210.6 cm |
| Bucket Hinge Pin | 130.0 in. | 330.2 cm |
| Width | 70.0 in. | 177.8 cm |
| Length | 160.0 in. | 406.4 cm |
| Dump Height | 100.0 in. | 254.0 cm |
| Dump Reach | 40.0 in. | 101.6 cm |
| Ground Clearance | 12.0 in. | 30.5 cm |
| Dump Angle | 41° |
| Rollback Angle | 31° |
| Departure Angle | 24° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 17.7 in. | 45.0 cm |
| Track Length | 128.0 in. | 325.1 cm |
| Ground Contact Length | 52.0 in. | 132.0 cm |
