| Manufacturer | New Holland |
| Model | C362 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2020-2026 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 114 HP | 85.0 kW |
| Lifting Capacity (35% Tipping) | 4340 lbs | 1969 kg |
| Lifting Capacity (50% Tipping) | 6200 lbs | 2812 kg |
| Operating Weight | 16100 lbs | 7311 kg |
| Tipping Load | 12500 lbs | 5670 kg |
| Lift Breakout Force | 12084 lbs | 5480 kg |
| Tilt Breakout Force | 12907 lbs | 5855 kg |
| Max. Travel Speed | 5.0 mph | 8.0 km |
| Optional High Speed | 8.7 mph | 14.0 km |
| Ground Pressure | 6.1 psi | 42.1 kPa |
Cycle Time
| Raise Lift Arms | 4.18 sec. |
| Lower Lift Arms | 2.18 sec. |
| Bucket Rollback | 1.6 sec. |
| Bucket Dump | 2.7 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 24.2 GPM | 91.5 LPM |
| Relief Pressure | 3450 psi | 237.0 Bar |
| Optional Flow | 41.6 GPM | 157.5 LPM |
| Hydraulic Capacity | 10.7 gal | 40.5 L |
Engine Specs
| Manufacturer | FPT |
| Model | F5BFL413D*C005 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 Final |
| Rated Speed | 2500 RPM |
| Torque Power | 1400 RPM |
| Combustion | Direct injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 114 HP | 85.0 kW |
| Net Power | 114 HP | 85.0 kW |
| Displacement | 207 cu in. | 3392 cc |
| Bore | 3.9 in. | 9.9 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | 339 ft-lb | 460 N∙m |
| Coolant Capacity | 3.3 gal | 12.4 L |
| Engine Oil Capacity | 2.4 gal | 8.5 L |
| Fuel Tank Capacity | 30.8 gal | 116.5 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 84.9 in. | 215.0 cm |
| Bucket Hinge Pin | 133.3 in. | 338.6 cm |
| Width | 78.3 in. | 198.8 cm |
| Length | 159.1 in. | 404.1 cm |
| Dump Height | 99.2 in. | 251.9 cm |
| Dump Reach | 39.0 in. | 99.0 cm |
| Ground Clearance | 12.6 in. | 32.1 cm |
| Dump Angle | 46.1° |
| Rollback Angle | 30° |
| Departure Angle | 38° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 17.7 in. | 45.0 cm |
| Track Length | 129.5 in. | 329.0 cm |
| Ground Contact Length | 66.0 in. | 167.7 cm |
