| Manufacturer | New Holland |
| Model | L120 |
| Type | Skid steer loader |
| Lift Design | Radial |
| Years Made | 2005-2009 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 18.0 HP | 13.3 kW |
| Lifting Capacity (35% Tipping) | 470 lbs | 213.2 kg |
| Lifting Capacity (50% Tipping) | 600 lbs | 271.7 kg |
| Operating Weight | 2050 lbs | 931.9 kg |
| Tipping Load | 1137 lbs | 516.3 kg |
| Lift Breakout Force | 1409 lbs | 635.0 kg |
| Tilt Breakout Force | 1150 lbs | 635.8 kg |
| Max. Travel Speed | 5.8 mph | 9.3 km |
Cycle Time
| Raise Lift Arms | 5.5 sec. |
| Lower Lift Arms | 3.4 sec. |
| Bucket Rollback | 1.9 sec. |
| Bucket Dump | 0.9 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 8.0 GPM | 30.3 LPM |
| Relief Pressure | 1600 psi | 110.3 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 9.0 gal | 34.1 L |
Engine Specs
| Manufacturer | Kohler |
| Model | CH18 |
| Type | Gas |
| Cylinders | 2 |
| Emissions | Tier 3 |
| Rated Speed | 2900 RPM |
| Torque Power | 1700 RPM |
| Combustion | |
| Compression Ratio | |
| Firing Order |
| US | Metric | |
|---|---|---|
| Gross Power | 18.0 HP | 13.3 kW |
| Net Power | 16.2 HP | 12.1 kW |
| Displacement | 38.1 cu in. | 624 cc |
| Bore | 3.0 in. | 7.7 cm |
| Stroke | 2.6 in. | 6.7 cm |
| Peak Torque | 30 ft-lb | 40 N∙m |
| Coolant Capacity | N/A | – |
| Engine Oil Capacity | 0.8gal | 3.0 L |
| Fuel Tank Capacity | 6.0 gal | 22.7 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 69.4 in. | 176.3 cm |
| Bucket Hinge Pin | 93.6 in. | 237.7 cm |
| Width | 31.8 in. | 80.8 cm |
| Length | 95.2 in. | 241.8 cm |
| Dump Height | 61.8 in. | 157.0 cm |
| Dump Reach | 21.4 in. | 54.4 cm |
| Ground Clearance | 6.8 in. | 17.3 cm |
| Dump Angle | 34.3° |
| Rollback Angle | 25° |
| Departure Angle | 16° |
