New Holland L150 Specs

New Holland L150 Specs
ManufacturerNew Holland
ModelL150
TypeSkid steer loader
Lift DesignRadial
Years Made2006-2012

Operating Specifications

USMetric
Horsepower38.0 HP28.4 kW
Lifting Capacity (35% Tipping)900 lbs408.2 kg
Lifting Capacity (50% Tipping)1350 lbs612.3 kg
Operating Weight4500 lbs2042.2 kg
Tipping Load2700 lbs1224.7 kg
Lift Breakout Force2400 lbs1088.6 kg
Tilt Breakout Force3500 lbs1589.4 kg
Max. Travel Speed7.3 mph11.8 km

Cycle Time

Raise Lift Arms3.1 sec.
Lower Lift Arms3.5 sec.
Bucket Rollback1.4 sec.
Bucket Dump1.6 sec.

Hydraulic System

USMetric
Pump Flow11.6 GPM43.9 LPM
Relief Pressure2500 psi172 Bar
Optional FlowN/A
Hydraulic Capacity5.0 gal18.9 L

Engine Specs

ManufacturerNew Holland
ModelN843H
TypeDiesel
Cylinders3
EmissionsTier 3
Rated Speed3200 RPM
Torque Power1900 RPM
CombustionIndirect injection
Compression Ratio18.5:1
Firing Order1-2-3
USMetric
Gross Power38.0 HP28.4 kW
Net Power36.0 HP26.9 kW
Displacement91.4 cu in.1498 cc
Bore3.3 in.8.4 cm
Stroke3.9 in.9.9 cm
Peak Torque73 ft-lb99 N∙m
Coolant Capacity1.6 gal6.0 L
Engine Oil Capacity1.6 gal6.2 L
Fuel Tank Capacity8.7 gal33.0 L

Dimensions

USMetric
Height74.1 in.188.3 cm
Bucket Hinge Pin115.8 in.294.0 cm
Width60.0 in.152.4 cm
Length121.3 in.308.1 cm
Dump Height92.2 in.234.1 cm
Dump Reach19.8 in.50.5 cm
Ground Clearance8.5 in.21.5 cm
Dump Angle45°
Rollback Angle35°
Departure Angle28°

Tire Size

Front10×16.5
Rear10×16.5
