| Manufacturer | New Holland |
| Model | L180 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2008-2012 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.0 HP | 55.2 kW |
| Lifting Capacity (35% Tipping) | 1550 lbs | 703.1 kg |
| Lifting Capacity (50% Tipping) | 2200 lbs | 997.9 kg |
| Operating Weight | 7130 lbs | 3234.1 kg |
| Tipping Load | 4400 lbs | 1995.8 kg |
| Lift Breakout Force | 4194 lbs | 1902.4 kg |
| Tilt Breakout Force | 6034 lbs | 2735.0 kg |
| Max. Travel Speed | 7.0 mph | 11.2 km |
| Optional High Speed | 11.3 mph | 18.2 km |
Cycle Time
| Raise Lift Arms | 2.8 sec. |
| Lower Lift Arms | 1.8 sec. |
| Bucket Rollback | 1.6 sec. |
| Bucket Dump | 2.5 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 21.0 GPM | 79.5 LPM |
| Relief Pressure | 3050 psi | 210.3 Bar |
| Optional Flow | 35.8 GPM | 135.5 LPM |
| Hydraulic Capacity | 5.0 gal | 18.9 L |
Engine Specs
| Manufacturer | FPT |
| Model | F5C E9454 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 3 |
| Rated Speed | 2600 RPM |
| Torque Power | 1400 RPM |
| Combustion | |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.0 HP | 55.2 kW |
| Net Power | 69.0 HP | 51.5 kW |
| Displacement | 195 cu in. | 3195 cc |
| Bore | 3.9 in. | 9.9 cm |
| Stroke | 4.1 in. | 10.4 cm |
| Peak Torque | 203 ft-lb | 275.2 N∙m |
| Coolant Capacity | 3.0 gal | 11.4 L |
| Engine Oil Capacity | 2.2 gal | 8.5 L |
| Fuel Tank Capacity | 22.9 gal | 86.7 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 78.7 in. | 199.9 cm |
| Bucket Hinge Pin | 126.8 in. | 321.9 cm |
| Width | 71.3 in. | 181.1 cm |
| Length | 150.3 in. | 381.8 cm |
| Dump Height | 94.7 in. | 240.6 cm |
| Dump Reach | 39.5 in. | 100.3 cm |
| Ground Clearance | 8.9 in. | 22.6 cm |
| Dump Angle | 45° |
| Rollback Angle | 37° |
| Departure Angle | 26° |
