| Manufacturer | New Holland |
| Model | L323 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2020-2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.0 HP | 55.2 kW |
| Lifting Capacity (35% Tipping) | 1600 lbs | 725.7 kg |
| Lifting Capacity (50% Tipping) | 2250 lbs | 1020.6 kg |
| Operating Weight | 7400 lbs | 3350.2 kg |
| Tipping Load | 5080 lbs | 2045.1 kg |
| Lift Breakout Force | 5080 lbs | 2304.2 kg |
| Tilt Breakout Force | 8620 lbs | 3910.0 kg |
| Max. Travel Speed | 7.0 mph | 11.2 km |
| Optional High Speed | 10.5 mph | 16.9 km |
Cycle Time
| Raise Lift Arms | 3.9 sec. |
| Lower Lift Arms | 2.5 sec. |
| Bucket Rollback | 2.0 sec. |
| Bucket Dump | 2.7 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 22.5 GPM | 85.0 LPM |
| Relief Pressure | 3046 psi | 210.0 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 12.0 gal | 45.4 L |
Engine Specs
| Manufacturer | FPT |
| Model | F5C E5454 G*A001 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4F |
| Rated Speed | 2500 RPM |
| Torque Power | 1400 RPM |
| Combustion | Direct injection |
| Compression Ratio | 17:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.0 HP | 55.2 kW |
| Net Power | 68.0 HP | 50.7 kW |
| Displacement | 195 cu in. | 3195 cc |
| Bore | 3.9 in. | 9.9 cm |
| Stroke | 4.1 in. | 10.4 cm |
| Peak Torque | 203 ft-lb | 275 N∙m |
| Coolant Capacity | 3.3 gal | 12.5 L |
| Engine Oil Capacity | 2.4 gal | 9.1 L |
| Fuel Tank Capacity | 25.5 gal | 96.5 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 78.9 in. | 200.4 cm |
| Bucket Hinge Pin | 129.5 in. | 329.0 cm |
| Width | 69.8 in. | 177.3 cm |
| Length | 147.1 in. | 373.6 cm |
| Dump Height | 100.2 in. | 254.4 cm |
| Dump Reach | 31.9 in. | 81.0 cm |
| Ground Clearance | 8.0 in. | 20.4 cm |
| Dump Angle | 54.7° |
| Rollback Angle | 33.6° |
| Departure Angle | 23.5° |
