Manufacturer New Holland Model L865 Type Skid steer loader Lift Design Vertical Years Made 1994-1999
There are very small specifications differences between the New Holland L865 and LX865 models. The New Holland LX865 has an ergonomic cabin design and precise control, providing the operator with a more comfortable and efficient use.
Operating Specifications
US Metric Horsepower 67.0 HP 50.0 kW Lifting Capacity (35% Tipping) 1700 lbs 771.1 kg Lifting Capacity (50% Tipping) 2200 lbs 997.8 kg Operating Weight 6955 lbs 3155.1 kg Tipping Load Lift Breakout Force Tilt Breakout Force Max. Travel Speed 7.6 mph 12.2 km Optional High Speed N/A –
Cycle Time
Raise Lift Arms 3.6 sec. Lower Lift Arms 1.5 sec. Bucket Rollback 1.8 sec. Bucket Dump 2.4 sec.
Hydraulic System
US Metric Pump Flow 17.6 GPM 66.6 LPM Relief Pressure 2600 psi 176.3 Bar Optional Flow 31.0 GPM 117.3 LPM Hydraulic Capacity 6.5 gal 25.5 L
Engine Specs
Manufacturer New Holland Model 332T Type Diesel Cylinders 3 Emissions N/A Rated Speed 2200 RPM Torque Power 1400 RPM Combustion Indirect injection Compression Ratio 17:5.1 Firing Order 1-2-3
US Metric Gross Power 67.0 HP 50.0 kW Net Power 60.0 HP 44.7 kW Displacement 192 cu in. 3146 cc Bore 4.4 in. 11.2 cm Stroke 4.2 in. 10.7 cm Peak Torque 184.5 ft-lb 250 N∙m Coolant Capacity 4.0 gal 15.1 L Engine Oil Capacity 3.6 gal 13.6 L Fuel Tank Capacity 18.8 gal 71.2 L
Dimensions
US Metric Height 78.0 in. 198.1 cm Bucket Hinge Pin 125.4 in. 318.3 cm Width 72.0 in. 182.9 cm Length 140.1 in. 355.9 cm Dump Height 100.5 in. 255.3 cm Dump Reach 31.3 in. 79.4 cm Ground Clearance 8.1 in. 20.6 cm
Dump Angle 47° Rollback Angle 37° Departure Angle 24°
