Manufacturer | New Holland |
Model | LS190.B |
Type | Skid steer loader |
Lift Design | Vertical |
Years Made | 2004-2007 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 80.0 HP | 59.7 kW |
Lifting Capacity (35% Tipping) | 2100 lbs | 952.5 kg |
Lifting Capacity (50% Tipping) | 2800 lbs | 1270.0 kg |
Operating Weight | 7860 lbs | 3565.2 kg |
Tipping Load | 5602 lbs | 2541.0 kg |
Lift Breakout Force | 5200 lbs | 2358.7 kg |
Tilt Breakout Force | 6034 lbs | 2737.3 kg |
Max. Travel Speed | 7.0 mph | 11.7 km |
Optional High Speed | 11.4 mph | 18.3 km |
Cycle Time
Raise Lift Arms | |
Lower Lift Arms | |
Bucket Rollback | |
Bucket Dump |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 21.9 GPM | 82.9 LPM |
Relief Pressure | 3050 psi | 210.3 Bar |
Optional Flow | 37.3 GPM | 141.2 LPM |
Hydraulic Capacity |
Engine Specs
Manufacturer | CNH |
Model | 445M2 |
Type | Diesel |
Cylinders | 4 |
Emissions | Tier II |
Rated Speed | 2300 RPM |
Torque Power | 1400 RPM |
Combustion | Direct injection |
Compression Ratio | |
Firing Order | 1-3-4-2 |
US | Metric | |
---|---|---|
Gross Power | 80.5 HP | 60.0 kW |
Net Power | 74.0 HP | 55.2 kW |
Displacement | 274 cu in. | 4490 cc |
Bore | 4.1 in. | 10.4 cm |
Stroke | 5.2 in. | 13.2 cm |
Peak Torque | 236 ft-lb | 320 N∙m |
Coolant Capacity | 4.5 gal | 17.0 L |
Engine Oil Capacity | 3.2 gal | 12.1 L |
Fuel Tank Capacity | 21.5 gal | 81.4 L |
Dimensions
US | Metric | |
---|---|---|
Height | 79.5 in. | 202.2 cm |
Bucket Hinge Pin | 125.6 in. | 319.0 cm |
Width | 76.5 in. | 194.3 cm |
Length | 146.0 in. | 370.8 cm |
Dump Height | 102.0 in. | 259.1 cm |
Dump Reach | 32.1 in. | 81.5 cm |
Ground Clearance | 10.1 in. | 25.7 cm |
Dump Angle | 45° |
Rollback Angle | 37° |
Departure Angle | 27° |
