| Manufacturer | Volvo |
| Model | MC70 |
| Type | Skid steer loader |
| Lift Design | Radial |
| Years Made | 2003-2005 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 60.0 HP | 44.7 kW |
| Lifting Capacity (35% Tipping) | ||
| Lifting Capacity (50% Tipping) | 1500 lbs | 680 kg |
| Operating Weight | 5902 lbs | 2677 kg |
| Tipping Load | 3000 lbs | 1360 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 7.0 mph | 11.1 km |
Cycle Time
| Raise Lift Arms | 3.9 sec. |
| Lower Lift Arms | 2.6 sec. |
| Bucket Rollback | 2.3 sec. |
| Bucket Dump | 2.7 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 16.6 GPM | 63.0 LPM |
| Relief Pressure | 2500 psi | 172 Bar |
| Optional Flow | 30.6 GPM | 116 LPM |
| Hydraulic Capacity | 9.5 gal | 36.0 L |
Engine Specs
| Manufacturer | Kubota |
| Model | V2003-TB |
| Type | Diesel |
| Cylinders | 4 |
| Rated Speed | 2800 RPM |
| Torque Power | 1600 RPM |
| Combustion | Spherical Type (E-TVCS) |
| Compression Ratio | 22.1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 60.0 HP | 44.7 kW |
| Displacement | 122 cu.in. | 2000 cc |
| Bore | 3.3 in. | 8.3 cm |
| Stroke | 3.6 in. | 9.2 cm |
| Peak Torque | 125 ft-lb | 169 N∙m |
| Coolant Capacity | 4.0 gal | 15.1 L |
| Engine Oil Capacity | 2.2 gal | 8.5 L |
| Fuel Tank Capacity | 17.4 gal | 65.7 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 77.9 in. | 197.9 cm |
| Bucket Hinge Pin | 113.8 in. | 289.1 cm |
| Width | 65.4 in. | 166.0 cm |
| Length | 133.6 in. | 339.4 cm |
| Dump Height | 85.1 in. | 216.2 cm |
| Dump Reach | 26.5 in. | 67.3 cm |
| Ground Clearance | 8.2 in. | 20.9 cm |
| Dump Angle | 37° |
| Rollback Angle | 27° |
| Departure Angle | 21° |
