Cat 247b3 vs Cat 257b3

Specifications Cat 247b3
Cat 247b3
Cat 257b3
Cat 257b3
Lift DesignVerticalVertical
Years Made2011-20142011-2013
Horsepower62.0 HP75.0 HP
Lifting Capacity (35% Tipping)1505 lbs1870 lbs
Lifting Capacity (50% Tipping)2150 lbs2675 lbs
Operating Weight7000 lbs8060 lbs
Tipping Load4300 lbs5350 lbs
Max. Travel Speed7.0 mph6.9 mph
Pump Flow16.0 GPM22.0 GPM
Relief Pressure3335 psi3335 psi
High FlowN/A
Peak Torque153 ft-lb148 ft-lb
Bucket Hinge Pin112.0 in.121.0 in.
Length129.0 in.135.0 in.
Dump Height84.0 in.91.0 in.
Dump Reach25.0 in.30.0 in.
Track Length107.0 in.107.0 in.
Ground Contact Length59.0 in.59.0 in.
  • Cat 257b3 has better Horsepower.
  • Cat 257b3 has better Weight.
  • Cat 257b3 has better Lifting Capacity.
  • Cat 257b3 has better Tipping Load.
  • Cat 247b3 has better Travel Speed.
  • Cat 247b3 has better Peak Torque.
  • Cat 257b3 has better Pin Height.
