John Deere 325g vs Cat 259d

Published Date: 13/06/2025
Last Check: 13/06/2025

Specifications	John Deere 325g	Cat 259d
Lift Design	Vertical	Vertical
Years Made	2018-2025	2015-2020
Horsepower	74.0 HP	74.3 HP
Lifting Capacity (35% Tipping)	2600 lbs	2030 lbs
Lifting Capacity (50% Tipping)	3700 lbs	2900 lbs
Operating Weight	9500 lbs	8846 lbs
Tipping Load	7400 lbs	5800 lbs
Max. Travel Speed	5.3 mph	8.5 mph
Pump Flow	21.0 GPM	20.0 GPM
Relief Pressure	3450 psi	3335 psi
High Flow	–	30.0 GPM
Optional Flow	32.0 GPM	–
Peak Torque	207 ft-lb	159 ft-lb
Bucket Hinge Pin	126.1 in.	121.0 in.
Length	136.3 in.	137.3 in.
Dump Height	102.1 in.	89.9 in.
Dump Reach	29.7 in.	23.9 in.
Track Length	112.3 in.	108.9 in.
Ground Contact Length	84.0 in.	59.0 in.

✅ Cat 259d has better Horsepower.
✅ John Deere 325g has better Weight.
✅ John Deere 325g has better Lifting Capacity.
✅ John Deere 325g has better Tipping Load.
✅ Cat 259d has better Travel Speed.
✅ John Deere 325g has better Peak Torque.
✅ John Deere 325g has better Pin Height.
