| Manufacturer | Wacker Neuson |
| Model | SM60 |
| Type | Mini skid steer |
| Lift Design | Radial |
| Years Made | 2021-2026 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 24.9 HP | 18.6 kW |
| Lifting Capacity (35% Tipping) | 602 lbs | 273 kg |
| Lifting Capacity (50% Tipping) | 860 lbs | 390 kg |
| Operating Weight | 2760 lbs | 1252 kg |
| Tipping Load | 1700 lbs | 772 kg |
| Lift Breakout Force | 1450 lbs | 658 kg |
| Tilt Breakout Force | 2498 lbs | 1133 kg |
| Max. Travel Speed | 3.9 mph | 6.3 km |
| Ground Pressure | 4.4 psi | 30.3 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 12.2 GPM | 46.2 LPM |
| Relief Pressure | 3045 psi | 210.0 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity |
Engine Specs
| Manufacturer | Kohler |
| Model | ECH749 |
| Type | Gasoline |
| Cylinders | 2 |
| Emissions | Tier 4F |
| Rated Speed | 1800 RPM |
| Torque Power | |
| Combustion | Direct injection |
| Compression Ratio | 9.0:1 |
| Firing Order | 1-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 24.9 HP | 18.6 kW |
| Net Power | 24.9 HP | 18.6 kW |
| Displacement | 45.6 cu in. | 747 cc |
| Bore | 3.3 in. | 8.3 cm |
| Stroke | 2.7 in. | 6.9 cm |
| Peak Torque | ||
| Coolant Capacity | ||
| Engine Oil Capacity | ||
| Fuel Tank Capacity | 14.0 gal | 53.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 54.8 in. | 139.2 cm |
| Bucket Hinge Pin | 75.6 in. | 192.0 cm |
| Width | 35.5 in. | 90.2 cm |
| Length | 98.5 in. | 250.2 cm |
| Dump Height | ||
| Dump Reach | ||
| Ground Clearance | 6.8 in. | 17.3 cm |
| Dump Angle | 37° |
| Rollback Angle | 25° |
| Departure Angle | 23° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 7.0 in. | 17.8 cm |
| Track Length | 75.6 in. | 192.0 cm |
| Ground Contact Length | 32.5 in. | 82.6 cm |
