| Manufacturer | Wacker Neuson |
| Model | ST27 |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2023-2025 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.3 HP | 55.5 kW |
| Lifting Capacity (35% Tipping) | 1889 lbs | 857 kg |
| Lifting Capacity (50% Tipping) | ||
| Operating Weight | 7350 lbs | 3334 kg |
| Tipping Load | 5401 lbs | 2450 kg |
| Lift Breakout Force | 4783 lbs | 2170 kg |
| Tilt Breakout Force | 5404 lbs | 2451 kg |
| Max. Travel Speed | 9.1 mph | 12.6 km |
| Ground Pressure | 4.4 psi | 30.3 kPa |
Cycle Time
| Raise Lift Arms | 3.3 sec. |
| Lower Lift Arms | 2.8 sec. |
| Bucket Rollback | 2.1 sec. |
| Bucket Dump | 2.2 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 19.3 GPM | 70.0 LPM |
| Relief Pressure | 4480 psi | 309 Bar |
| Optional High Flow | 28.8 GPM | 109.0 LPM |
| Hydraulic Capacity | 7.7 gal | 29.1 L |
Engine Specs
| Manufacturer | Kohler |
| Model | KDI2504TCR |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 Final |
| Rated Speed | 2600 RPM |
| Torque Power | 1200 RPM |
| Combustion | Direct injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.3 HP | 55.5 kW |
| Net Power | ||
| Displacement | 151 cu in. | 2482 cc |
| Bore | 3.5 in. | 8.8 cm |
| Stroke | 4.0 in. | 10.2 cm |
| Peak Torque | ||
| Coolant Capacity | 3.4 gal | 13.0 L |
| Engine Oil Capacity | 2.5 gal | 9.5 L |
| Fuel Tank Capacity | 27.2 gal | 103.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 79.8 in. | 200.1 cm |
| Bucket Hinge Pin | 119.9 in. | 302.3 cm |
| Width | 60.0 in. | 165.2 cm |
| Length | 132.0 in. | 349.0 cm |
| Dump Height | 94.3 in. | 229.4 cm |
| Dump Reach | 39.2 in. | 121.2 cm |
| Ground Clearance | 8.5 in. | 23.3 cm |
| Dump Angle | 37° |
| Rollback Angle | 30° |
| Departure Angle | 29.9° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 12.6 in. | 32.0 cm |
| Track Length | 102.5 in. | 253.4 cm |
| Ground Contact Length | 53.2 in. | 135.1 cm |
