| Manufacturer | Wacker Neuson |
| Model | SW24 |
| Type | Skid steer loader |
| Lift Design | Radial |
| Years Made | 2015-2021 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.0 HP | 55.2 kW |
| Lifting Capacity (35% Tipping) | 1600 lbs | 726 kg |
| Lifting Capacity (50% Tipping) | 2350 lbs | 1066 kg |
| Operating Weight | 7865 lbs | 3568 kg |
| Tipping Load | 5000 lbs | 2268 kg |
| Lift Breakout Force | 5309 lbs | 2408 kg |
| Tilt Breakout Force | 6717 lbs | 3047 kg |
| Max. Travel Speed | 11.2 mph | 18.0 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 22.5 GPM | 85.2 LPM |
| Relief Pressure | 3338 psi | 230 Bar |
| Optional Flow | 35.9 GPM | 135.9 LPM |
| Hydraulic Capacity | 2.9 gal | 11.0 L |
Engine Specs
| Manufacturer | Perkins |
| Model | 854 |
| Type | Diesel |
| Cylinders | 4 |
| Rated Speed | 2500 RPM |
| Torque Power | 1600 RPM |
| Combustion | Direct injection |
| Emissions | Tier 4 |
| Compression Ratio | 17.1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.0 HP | 55.2 kW |
| Net Power | 73.8 HP | 55.0 kW |
| Displacement | 207 in. | 3397 cc |
| Bore | 3.9 in. | 9.9 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | ||
| Coolant Capacity | 1.5 gal | 6.0 L |
| Engine Oil Capacity | 2.2 gal | 8.5 L |
| Fuel Tank Capacity | 24.3 gal | 92.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 81.9 in. | 208.0 cm |
| Bucket Hinge Pin | 125.2 in. | 318.0 cm |
| Width | 70.0 in. | 177.8 cm |
| Length | 144.2 in. | 366.3 cm |
| Dump Height | 95.2 in. | 241.8 cm |
| Dump Reach | ||
| Ground Clearance | 9.4 in. | 23.9 cm |
| Dump Angle | 45° |
| Rollback Angle | |
| Departure Angle | 25° |
