| Manufacturer | Bobcat |
| Model | MT100 |
| Type | Mini track loader |
| Lift Design | Radial |
| Years Made | Unknown |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 25.0 HP | 18.6 kW |
| Lifting Capacity (35% Tipping) | 1000 lbs | 453.6 kg |
| Lifting Capacity (50% Tipping) | 1250 lbs | 567.0 kg |
| Operating Weight | 3390 lbs | 1537.7 kg |
| Tipping Load | 2898 lbs | 1314.5 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 4.1 mph | 6.6 km |
| Ground Pressure | 5.2 psi | 35.9 kPa |
Cycle Time
| Raise Lift Arms | 3.2 sec. |
| Lower Lift Arms | 3.0 sec. |
| Bucket Rollback | 1.6 sec. |
| Bucket Dump | 1.8 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 11.0 GPM | 41.6 LPM |
| Relief Pressure | 2900 psi | 199.9 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 5.3 gal | 20.1 L |
Engine Specs
| Manufacturer | Kubota |
| Model | D902-E3B-BC-1 |
| Type | Diesel |
| Cylinders | 3 |
| Emissions | Tier 4 |
| Rated Speed | 3600 RPM |
| Torque Power | 2600 RPM |
| Combustion | Indirect injection |
| Compression Ratio | 24:1 |
| Firing Order | 1-2-3 |
| US | Metric | |
|---|---|---|
| Gross Power | 25.0 HP | 18.5 kW |
| Displacement | 54.8 cu in. | 898 cc |
| Bore | 2.8 in. | 7.1 cm |
| Stroke | 2.9 in. | 7.3 cm |
| Peak Torque | 39.9 ft-lb | 54.2 N∙m |
| Coolant Capacity | 1.7 gal | 6.6 L |
| Engine Oil Capacity | 1.0 gal | 3.6 L |
| Fuel Tank Capacity | 7.0 gal | 26.5 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 54.6 in. | 138.7 cm |
| Bucket Hinge Pin | 80.9 in. | 205.5 cm |
| Width | 35.6 in. | 90.4 cm |
| Length | 106.2 in. | 269.7 cm |
| Dump Height | 80.9 in. | 205.5 cm |
| Dump Reach | 18.6 in. | 47.2 cm |
| Ground Clearance | 8.0 in. | 20.3 cm |
| Dump Angle | 48° |
| Rollback Angle | 22° |
| Departure Angle | 23° |
Find Bobcat MT100 Parts on Amazon
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 7.0 in. | 17.8 cm |
| Track Length | 84.5 in. | 214.6 cm |
| Ground Contact Length | 41.4 in. | 105.2 cm |
