Case TR310B Specs

case tr310b skid steer
ManufacturerCase
ModelTR310B
TypeCompact track loader
Lift DesignRadial
Years Made2019-2025

The Case TR310B features a more advanced control system compared to the TR310, with adjustable electro-hydraulic joystick sensitivity and the ability to switch between H and ISO patterns. The TR310B also includes a high-resolution 8” LCD display, economy mode, and engine protection as additional electronic features. It comes factory-equipped with a two-speed drive system, enhancing maneuverability on the job site. Apart from minor dimensional differences, the TR310B does not offer many significant specifications changes over the TR310.

Operating Specifications

USMetric
Horsepower74.0 HP55.2 kW
Lifting Capacity (35% Tipping)2170 lbs857.3 kg
Lifting Capacity (50% Tipping)3100 lbs1406.1 kg
Operating Weight8880 lbs4027.9 kg
Tipping Load6200 lbs2812.3 kg
Lift Breakout Force6440 lbs2921.1 kg
Tilt Breakout Force8680 lbs3937.2 kg
Max. Travel Speed5.1 mph8.2 km
Optional High Speed8.0 mph12.2 km
Ground Pressure5.0 psi34.5 kPa

Cycle Time

Raise Lift Arms4.3 sec.
Lower Lift Arms2.6 sec.
Bucket Rollback1.9 sec.
Bucket Dump2.3 sec.

Hydraulic System

USMetric
Pump Flow24.2 GPM91.5 LPM
Relief Pressure3046 psi210.0 Bar
Optional Flow32.4 GPM122.6 LPM
Hydraulic Capacity10.0 gal37.9 L

Engine Specs

ManufacturerFPT
ModelF5H FL463 A*G001
TypeDiesel
Cylinders4
EmissionsTier 4 Final
Rated Speed2500 RPM
Torque Power1400 RPM
CombustionDirect injection
Compression Ratio
Firing Order1-3-4-2
USMetric
Gross Power74.0 HP55.2 kW
Net Power68.0 HP50.7 kW
Displacement207 cu in.3392 cc
Bore3.9 in.9.9 cm
Stroke4.3 in.11.0 cm
Peak Torque232 ft-lb314.5 N∙m
Coolant Capacity
Engine Oil Capacity2.2 gal8.5 L
Fuel Tank Capacity19.5 gal73.8 L

Dimensions

USMetric
Height78.7 in.199.9 cm
Bucket Hinge Pin125.1 in.317.8 cm
Width74.3 in.188.7 cm
Length129.1 in.327.9 cm
Dump Height100.6 in.255.5 cm
Dump Reach25.6 in.65.0 cm
Ground Clearance8.0 in.20.3 cm
Dump Angle38.1°
Rollback Angle31.0°
Departure Angle32.0°

Undercarriage

USMetric
Track Width15.75 in.40.0 cm
Track Length104.8 in.266.2 cm
Ground Contact Length55.9 in.142.0 cm
