| Manufacturer | Gehl |
| Model | Ctl80 |
| Type | Compact track loader |
| Lift Design | Radial |
| Years Made | 2003-2008 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 94.5 HP | 72.0 kW |
| Lifting Capacity (35% Tipping) | 2570 lbs | 1165.7 kg |
| Lifting Capacity (50% Tipping) | 3530 lbs | 1601.2 kg |
| Operating Weight | 10650 lbs | 4830.8 kg |
| Tipping Load | 7050 lbs | 3197.8 kg |
| Lift Breakout Force | 8550 lbs | 3878.2 kg |
| Tilt Breakout Force | 8700 lbs | 3946.3 kg |
| Max. Travel Speed | 5.0 mph | 8.1 km |
| Optional High Speed | 6.9 mph | 11.1 km |
| Ground Pressure | 4.3 psi | 29.6 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 23.3 GPM | 88.2 LPM |
| Relief Pressure | 3000 psi | 206.8 Bar |
| Optional High Flow | N/A | N/A |
| Hydraulic Capacity | 16.9 gal | 64.0 L |
Engine Specs
| Manufacturer | Yanmar |
| Model | 4TNV106T-XTBL |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 3 |
| Rated Speed | 2200 RPM |
| Torque Power | 1400 RPM |
| Combustion | Direct injection |
| Compression Ratio | 18.0 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 96.1 HP | 71.7 kW |
| Net Power | 94.5 HP | 70.0 kW |
| Displacement | 269 cu in. | 4412 cc |
| Bore | 4.2 in. | 10.6 cm |
| Stroke | 4.9 in. | 12.5 cm |
| Peak Torque | 289 ft-lb | 393 N∙m |
| Coolant Capacity | 4.0 gal | 15.1 L |
| Engine Oil Capacity | 3.7 gal | 14.0 L |
| Fuel Tank Capacity | 28.5 gal | 107.9 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 87.0 in. | 221.0 cm |
| Bucket Hinge Pin | 126.0 in. | 320.0 cm |
| Width | 73.2 in. | 185.9 cm |
| Length | 156.9 in. | 398.5 cm |
| Dump Height | 94.0 in. | 238.8 cm |
| Dump Reach | 41.0 in. | 104.9 cm |
| Ground Clearance | 14.3 in. | 36.3 cm |
| Dump Angle | 37° |
| Rollback Angle | 32° |
| Departure Angle | 28° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 18.0 in. | 45.7 cm |
| Track Length | 122.0 in. | 310.6 cm |
| Ground Contact Length | 62.9 in. | 159.5 cm |
