| Manufacturer | John Deere |
| Model | 330G |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2016-2024 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 91.2 HP | 68.0 kW |
| Lifting Capacity (35% Tipping) | 2100 lbs | 952.5 kg |
| Lifting Capacity (50% Tipping) | 3000 lbs | 1360.8 kg |
| Operating Weight | 9900 lbs | 4495.2 kg |
| Tipping Load | 6000 lbs | 2721.5 kg |
| Lift Breakout Force | 7000 lbs | 3175.1 kg |
| Tilt Breakout Force | 4676 lbs | 2121.0 kg |
| Max. Travel Speed | 12.0 mph | 19.3 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 23.5 GPM | 89.0 LPM |
| Relief Pressure | 3450 psi | 237.9 Bar |
| Optional Flow | 36.5 GPM | 138.2 LPM |
| Hydraulic Capacity |
Engine Specs
| Manufacturer | Yanmar |
| Model | 4TNV94FHT |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 |
| Rated Speed | 2500 RPM |
| Torque Power | 1700 RPM |
| Combustion | Direct injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 91.2 HP | 68.0 kW |
| Net Power | 88.5 HP | 66.0 kW |
| Displacement | 186.3 cu in. | 3054 cc |
| Bore | 3.7 in. | 9.4 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | 282 ft-lb | 382 N∙m |
| Coolant Capacity | ||
| Engine Oil Capacity | ||
| Fuel Tank Capacity | 25.5 gal | 96.5 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 86.3 in. | 219.2 cm |
| Bucket Hinge Pin | 132.0 in. | 335.3 cm |
| Width | 78.0 in. | 198.1 cm |
| Length | 146.0 in. | 370.8 cm |
| Dump Height | 106.1 in. | 269.5 cm |
| Dump Reach | 28.0 in. | 71.1 cm |
| Ground Clearance | 9.7 in. | 24.6 cm |
| Dump Angle | 48° |
| Rollback Angle | 35° |
| Departure Angle | 29° |
