| Manufacturer | John Deere |
| Model | 4475 |
| Type | Skid steer loader |
| Lift Design | Radial |
| Years Made | 1994-1998 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 32.0 HP | 23.8 kW |
| Lifting Capacity (35% Tipping) | ||
| Lifting Capacity (50% Tipping) | 1250 lbs | 567 kg |
| Operating Weight | 4360 lbs | 1978 kg |
| Tipping Load | ||
| Lift Breakout Force | ||
| Tilt Breakout Force | 2600 lbs | 1179 kg |
| Max. Travel Speed | 6.5 mph | 10.5 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 11.0 GPM | 41.6 LPM |
| Relief Pressure | 2600 psi | 179.3 Bar |
| Optional Flow | N/A | – |
| Hydraulic Capacity | 9.0 gal | 33.9 L |
Engine Specs
| Manufacturer | John Deere (Yanmar) |
| Model | 3015D001 (3TNE84-JSL) |
| Type | Diesel |
| Cylinders | 3 |
| Emissions | N/A |
| Rated Speed | 3000 RPM |
| Torque Power | |
| Combustion | Direct injection |
| Compression Ratio | 18.0 |
| Firing Order | 1-2-3 |
| US | Metric | |
|---|---|---|
| Gross Power | 32.0 HP | 23.8 kW |
| Net Power | 31.0 HP | 23.1 kW |
| Displacement | 91.3 cu in. | 1496 cc |
| Bore | 3.3 in. | 8.4 cm |
| Stroke | 3.5 in. | 9.0 cm |
| Peak Torque | ||
| Coolant Capacity | 3.3 gal | 10.3 L |
| Engine Oil Capacity | 1.9 gal | 7.3 L |
| Fuel Tank Capacity | 12.0 gal | 45.4 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 72.4 in. | 183.9 cm |
| Bucket Hinge Pin | 111.1 in. | 282.2 cm |
| Width | 60.0 in. | 152.0 cm |
| Length | 120.0 in. | 305.0 cm |
| Dump Height | 87.9 in. | 223.0 cm |
| Dump Reach | 21.0 in. | 53 cm |
| Ground Clearance | 8.3 in. | 21 cm |
| Dump Angle | |
| Rollback Angle | 36° |
| Departure Angle | 26° |
