| Manufacturer | New Holland |
| Model | L334 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2021-2026 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 90.0 HP | 67.1 kW |
| Lifting Capacity (35% Tipping) | 2300 lbs | 1043.3 kg |
| Lifting Capacity (50% Tipping) | 3400 lbs | 1542.2 kg |
| Operating Weight | 8900 lbs | 4037.0 kg |
| Tipping Load | 6800 lbs | 3084.4 kg |
| Lift Breakout Force | 6918 lbs | 3138.0 kg |
| Tilt Breakout Force | 9323 lbs | 4228.8 kg |
| Max. Travel Speed | 7.7 mph | 12.4 km |
| Optional High Speed | 11.5 mph | 18.5 km |
Cycle Time
| Raise Lift Arms | 4.5 sec. |
| Lower Lift Arms | 3.4 sec. |
| Bucket Rollback | 2.0 sec. |
| Bucket Dump | 2.6 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 24.2 GPM | 91.6 LPM |
| Relief Pressure | 3450 psi | 237.9 Bar |
| Optional Flow | 37.6 GPM | 142.3 LPM |
| Hydraulic Capacity | 12.0 gal | 45.4 L |
Engine Specs
| Manufacturer | FPT |
| Model | F5BFL413E*B002 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4F |
| Rated Speed | 2500 RPM |
| Torque Power | 1400 RPM |
| Combustion | Direct injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 90.0 HP | 67.1 kW |
| Net Power | 84.0 HP | 62.6 kW |
| Displacement | 207 cu in. | 3392 cc |
| Bore | 3.9 in. | 9.9 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | 282 ft-lb | 383 N∙m |
| Coolant Capacity | 5.0 gal | 18.9 L |
| Engine Oil Capacity | 2.2 gal | 8.5 L |
| Fuel Tank Capacity | 25.5 gal | 96.5 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 80.4 in. | 204.2 cm |
| Bucket Hinge Pin | 131.0 in. | 332.7 cm |
| Width | 76.0 in. | 193.0 cm |
| Length | 153.1 in. | 389.0 cm |
| Dump Height | 98.2 in. | 249.5 cm |
| Dump Reach | 36.6 in. | 93.0 cm |
| Ground Clearance | 9.6 in. | 24.3 cm |
| Dump Angle | 48° |
| Rollback Angle | 33° |
| Departure Angle | 27° |
