| Manufacturer | New Holland |
| Model | LS180.B |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2005-2007 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 63.0 HP | 47.0 kW |
| Lifting Capacity (35% Tipping) | 1650 lbs | 750 kg |
| Lifting Capacity (50% Tipping) | 2200 lbs | 1090 kg |
| Operating Weight | 7100 lbs | 3220 kg |
| Tipping Load | 4800 lbs | 2177 kg |
| Bucket Breakout Force | 4193 lbs | 1902 kg |
| Boom Breakout Force | 6034 lbs | 2737 kg |
| Max. Travel Speed | 6.8 mph | 11.0 km |
| Optional High Speed | 11.2 mph | 18.0 km |
Cycle Time
| Raise Lift Arms | 3.0 sec. |
| Lower Lift Arms | 2.9 sec. |
| Bucket Rollback | |
| Bucket Dump | 2.2 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 19.3 GPM | 73.1 LPM |
| Relief Pressure | 3045 psi | 210 Bar |
| Optional Flow | 34.7 GPM | 131.4 LPM |
| Hydraulic Capacity | 15.0 gal | 56.8 L |
Engine Specs
| Manufacturer | New Holland |
| Model | 334M2 |
| Type | Diesel |
| Cylinders | 3 |
| Emissions | Tier 2 |
| Rated Speed | 2300 RPM |
| Torque Power | 1400 RPM |
| Combustion | Direct injection |
| Compression Ratio | 18.0:1 |
| Firing Order | 1-2-3 |
| US | Metric | |
|---|---|---|
| Gross Power | 73.0 HP | 54.4 kW |
| Net Power | 70.0 HP | 52.2 kW |
| Displacement | 207 cu in. | 3392 cc |
| Bore | 3.7 in. | 9.4 cm |
| Stroke | 3.9 in. | 10.0 cm |
| Peak Torque | 190 ft-lb | 266 N∙m |
| Coolant Capacity | 3.9 gal | 14.7 L |
| Engine Oil Capacity | 1.7 gal | 6.6 L |
| Fuel Tank Capacity | 18.0 gal | 68.1 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 77.8 in. | 197.5 cm |
| Bucket Hinge Pin | 124.6 in. | 316.5 cm |
| Width | 71.3 in. | 181.0 cm |
| Length | 138.8 in. | 352.5 cm |
| Dump Height | 100.0 in. | 254.0 cm |
| Dump Reach | 32.7 in. | 83.0 cm |
| Ground Clearance | 9.4 in. | 24.0 cm |
| Dump Angle | 45° |
| Rollback Angle | 37° |
| Departure Angle | 28° |
